When it comes to outfitting railings with reliable, long-lasting hardware, the choice of wall flange can make or break both safety and aesthetics. ESANG STAINLESS STEEL’s Stainless Steel Handrail Railing Round Tube Wall Flange is engineered to solve the most common pain points faced by contractors, hotel renovators, and architectural designers—from uneven ground challenges to corrosion in high-moisture areas. Crafted with premium materials and user-centric design, this flange ensures your handrail systems stay secure, visually polished, and low-maintenance for years.
| Surface: | Mirror & Polish Mirror & Polish Satin & Brushed Satin & Brushed |
|---|---|
| SKU: | |
| Availability: | |
| Quantity: | |
Contractors and designers often struggle with three key issues when installing handrail flanges: poor fit with tubes, difficulty adapting to uneven surfaces, and rapid wear in harsh environments. Our wall flange addresses each of these head-on:
No More Ill-Fitting Connections: Precision-engineered to match standard round tube sizes (38.1mm/1.5”, 50.8mm/2”), our flange eliminates gaps or loose fits that compromise safety. Whether you’re working with 1.5” or 2” tubes, it locks into place seamlessly—saving you time on adjustments.
Adjustable for Uneven Ground: Unlike rigid flanges that require perfectly level surfaces, our design includes adjustable bottom bolts. This feature lets you fine-tune the flange height to accommodate uneven walls or floors, avoiding costly rework or shimming.
Corrosion Resistance for Longevity: Made from food-grade 304 stainless steel (with 316 stainless steel options for coastal/high-humidity areas), our flange resists rust, tarnish, and chemical damage. It’s ideal for hotel lobbies, outdoor decks, or shower areas—where moisture and foot traffic would degrade lesser materials.
Tool-Free, DIY-Friendly Installation: With a pre-drilled flat base (treated for extra grip) and clear assembly instructions, you can install the flange in under 10 minutes—no specialized tools needed. This cuts down labor costs and keeps projects on schedule.
Our Stainless Steel Handrail Railing Round Tube Wall Flange is designed to meet ASTM standards, ensuring compliance with global architectural safety requirements. Below is a detailed breakdown of its key features:
| Specification | Details |
| Type | Handrail Wall Flange |
| Compatible Tube Sizes | 38.1mm (1.5”) Φ, 50.8mm (2”) Φ (other sizes available via customization) |
| Material Options | 304 Stainless Steel (standard), 316 Stainless Steel (corrosion-resistant) |
| Finish Types | Brushed Stainless Steel (matte, fingerprint-resistant), Polished Stainless Steel (mirror-like shine) |
| Design Style | Modern, minimalist (fits contemporary hotel/architectural designs) |
| Warranty | 5-Year Limited Warranty (covers material defects and corrosion) |
| Origin | Mainland China (ISO 9001-certified manufacturing facility) |
| Primary Applications | Hotel lobbies, stairwells, outdoor decks, commercial buildings, residential railings |
Not all stainless steel flanges are created equal. Generic products often cut corners on material quality or design—leading to premature failure. Here’s how ESANG stands out:
Prepare the Surface: Clean the wall/floor area where the flange will be mounted. Remove dust, grease, or debris to ensure the base adheres tightly.
Mark the Drilling Points: Place the flange on the desired location. Use a pencil to mark the holes (included in the base) for drilling.
Secure the Flange: Drill pilot holes (size: 6mm) into the marked spots. Insert expansion bolts (included in the package) through the flange holes and tighten with a wrench until the flange is firm.
Adjust for Level: If the surface is uneven, use the bottom adjustable bolts to raise or lower the flange. Use a level tool to confirm the flange is horizontal/vertical, then lock the bolts in place.
Attach the Tube: Slide the round tube into the flange’s neck. Tighten the set screw (included) with a hex key to secure the tube—your handrail is now ready to use!
Email: info@esangmetal.com
Phone & WhatsApp: +86-18022741432
Website: www.esangstainlesssteel.com
Custom Orders: Reach out to our team for 2D/3D drawings or prototype requests—we’ll respond within 48 hours.
